Description
Zastosowanie Dla instalacji monochromatycznych (jednokolorowych)
Input voltage - wall panel 180-240V AC
Maximum output current Depending on the applied receiver
Number of supported zones/channels From 1 to 4 zones
Communication method Radio
Radio transmission frequency 2.4GHz
Radio communication range Up to 30 meters in open terrain
Return to previous settings in case of power failure No
Touch buttons Yes
Glass panel Yes
Operating temperature of the wall panel -20? -:- 60?
Ingress protection class IP20
Device dimensions 86mm*86mm*33mm
Installation of wall panel Flush-mounted - box fi60
Color White
Declarations RoHs, CE
Warranty 24 months
FUT035S+ LED Receiver - MONO - 12-24V DC (10A)
IBOX1 Wi-Fi Module - iBox1
IBOX2 Moduł Wi-Fi - iBox2
We have made every effort to ensure that the above data is correct, but we do not guarantee that the published information does not contain errors, which cannot, however, constitute the basis for any claims..
