Symbol:
10-0031-10
EAN:
5901854771410
Parameters:
Operating voltage: 3 V (AAA*2 pcs.)
Power consumption in standby mode: 20μA
Transmission power: 6dBm
RF: 2.4 GHz
Modulation method: GFSK
Control distance: 30m
Dimensions: 53x21x110.5mm
Operating temperature: -10~40°C
Number of supported zones/channels: 4 zones
Degree of protection: IP20
Wall mount for the remote: none (ID-0099-Wall mount)
Safety declarations and standards: CE, RoHS,
Manufacturer's warranty: 24 months
Features:
Dimming and brightening lighting
Adjustment of white light temperature
Supports up to four zones
Suitable for MONO/CCT installations
Possibility to expand the installation at any time
Immediate reduction of light intensity for zones/zone
Pairing the controller:
1. Select the zone to which the controller should be assigned.
2.Disconnect the 12V DC power from the receiver.
3.Reconnect the 12V DC power to the receiver and within 3 seconds briefly press the selected zone on the remote.
4.If the pairing was successful, the light will blink 3 times.
