Description
Zastosowanie Dla instalacji monochromatycznych (jednokolorowych)
Maximum output current Depending on the applied receiver
Power supply of the transmitter Battery 2x 1.5V AAA
Number of supported zones/channels From 1 to 4 zones
Communication method Radio
Radio transmission frequency 2.4GHz
Radio communication range Up to 30 meters in open terrain
Touch buttons Yes
Glass panel Yes
Operating temperature of the wall panel -20? -:- 60?
Ingress protection class IP20
Device dimensions 86mm*86mm*21mm
Wall panel installation Surface-mounted
Color White
Declarations RoHs, CE
Warranty 24 months
FUT035S+ LED Receiver - MONO - 12-24V DC (10A)
IBOX1 Wi-Fi Module - iBox1
IBOX2 Moduł Wi-Fi - iBox2
We have made every effort to ensure that the above data is correct, but we do not guarantee that the published information does not contain errors, which cannot, however, constitute the basis for any claims..
