Parameters:

• Installation type: ON/OFF or ON/OFF+dimming

• Lighting control method: radio 2.4GHz, push button

• Output type of the controller: CV (constant voltage)

• Rated voltage: input/output - AC 100-240V 50/60Hz

• Maximum output current: 1.36A

• Maximum output power: 300W for 220V

• Number of controller outputs: 1 output

• Dimming method: Wireless RF dimming. Press the dimming button

• Communication range: up to 30 meters in open terrain with the possibility of extending through signal retransmission

• Return to previous settings when turned off from the transmitter: yes

• Compatibility with external systems: Amazon Alexa system, Google Assistant (voice)

• Operating temperature: from -10 to + 40°C

• Ingress protection class: IP20

• Installation: surface-mounted

• Dimensions: 49 x 49 x 25 mm

• Safety declarations and standards: CE, RoHs

• Manufacturer's warranty: 24 months

Features:

• Smartphone app control (gateway 2.4GHz must be purchased)

• Wireless remote control 2.4G RF

• Dimming function from the key

• Edge-cutting phase cutting technology

• 0~100% stepless dimming and flicker-free

• Built-in temperature detection switch and protection against overheating and overload

• The fireproof coating of the controller provides greater safety
