Protections:
overload (OCP),
overvoltage (OVP),
short-circuit (SCP),
thermal (OTP)
IP degree:
IP67
Housing type:
housing made of aluminum profile
External dimensions:
160 x 40 x 20mm
The electronic design ensures highresistance to fluctuations in mains voltage, especially to impulse voltage spikes.This is very important forprotecting sensitive LED diodesand other components.
The use of the transformer galvanically isolates the load from the power grid, which is fundamentallyimportant for electrical safetyof users. The output voltage of 24V is safe for people.
Due to the increased degree of protection (against the effects of temporary immersion in water and dust-tight protection), it will perform well in humid places and those exposed to rain, as well as in areas exposed to dust.
The installation should ensure air exchange for cooling the power supply. Possibility of mounting on 2 screws with a max. diameter of 4mm (screws not included).
